A small and sleek 4-port PoE injector to power PoE devices. Ethernet IN – 4 PoE+ Ethernet OUT. Supply voltage: 24 V DC Mounting: Wall or DIN rail. Supplied with wall mount and DIN mount.
Recommended environment | |
---|---|
Security class (IP-klass) | |
Recommended mounting | DIN rails, Wall |
Dimensioner (Höjd x Bredd x Djup) | 117 x 155 x 135 mm |
Net weight | |
Color | |
Voltage in (V) | 27.3 VDC |
Current out | PoE (48 V) |
Current in (A) | 5 A |
Number of LAN / PoE ports | 4 / 4 |
Max effect per port | 30.8 W |
PoE budget | 120 W |
Ethernet type | Injector |
Interface | 1000Base-T RJ-45 |
Network port type | 10 / 100 PoE+ |
Support for standard in accordance with | IEEE 802.3af, IEEE 802.3at |
Functions | Auto-negotiation, Auto-uplink (auto MDI/MDI-X) |
Manager bar | No |
Protection against | Excessive temperature, Over voltage, Overload, Short circuit |
In-stock article | No |
Normal dlivery time | |
Guarantee period | 2 years |
Product meets requirements in accordance with | CE directive in accordance with:765/2008, EMC Directive 2014/30EU, Emission: EN61000-6-:2001, EN55022:1998:-A1:2000, A2:2003 Class B, EN61000-3-2:2001, Immunity: EN61000-6-2:2005, EN61000-4-2, -3, 4, -5, -6, -11 |
Producer | Milleteknik AB |
Country of origin | |
Not | All specifications subject to change in event of product changes or incorrect data |
